Liberty AV 18-2C-P-WHT White Commercial Grade General Purpose 18 AWG 2 Conductor Plenum Cable

Liberty AV 18-2C-P-WHT White Commercial Grade General Purpose 18 AWG 2 Conductor Plenum Cable

Features and Benefits

7-strand annealed bare copper conductors
Plenum rated PVC insulation
Twisted, unshielded
Plenum rated PVC jacket
NEC CMP, CEC CMP FT6, RoHS compliant
1000 foot spools

Applications

Speaker level audio
70 volt speaker cabling
Class 2 and class 3 low voltage power
Instrumentation and control

20 lbs per 1k ft
11 lbs per 0.5k ft

Description	2 conductor 18 AWG stranded, twisted, and unshielded cable NEC type CMP and CEC type CMP FT6. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725 and 800.
Conductor	18 AWG 7-strand annealed bare copper conductors Diameter: 0.0454" \| 1.15mm
Electrical	DC resistance: 6.92 Ω / 1000’ \| 22.7 Ω/KM Mutual capacitance: 29.3 pF/FT \| 96.11 pF/M Impedance: 63 Ω Inductance: 0.15µH/FT \| 0.49µH/M Velocity of Propagation: 55% Voltage rating: 300V Maximum current: 3.75A@25°C
Insulation	Plenum rated polyvinyl chloride Wall thickness: 0.008" \| 0.20mm Diameter: 0.061" \| 1.56mm
Regulatory	NEC: CMP 75°C CEC: CMP FT6 60°C EU RoHS-2 2011/65/EU Compliant
Color Code	Black, Red
Packages	Reel: 1000’ \| 305M Weight: 20 Lbs/1000’ \| 30 Kg/KM
Assembly	2 conductors twisted Lay length: 3.0" \| 80mm 4.0 twists per foot \| 12.5 twists per meter
Installation	Pull Tension: 26 Lbs \| 116 N Bend radius: 1.54" \| 40mm unloaded Bend radius: 3.08" \| 80mm loaded Plenum cable should be conditioned at room temperature for 24 hours prior to installation and never installed below 32°F \| 0°C ambient temperature
Construct	Ripcord under jacket
Applications	Plenum security and low voltage power Plenum commercial and residential speaker level audio Plenum 70V commercial speaker audio Plenum Class 2 and 3 power
Shield	N/A
Performance	Speaker level audio to 30 feet
Jacket	Plenum rated polyvinyl chloride Colors: Natural White, Yellow, Black, Green Wall thickness: 0.014" \| 0.36mm Diameter: 0.154" \| 3.92mm
Final Outside Diameter (inches)	0.154
